High Power Pure Copper Pipe Heatsink

Basic Information
Place of Origin: China
Brand Name: Customized
Certification: ISO9001:2015
Model Number: HEAT SINK-H0012
Minimum Order Quantity: Negotiable
Packaging Details: Blister packaging
Delivery Time: 20-30days
Payment Terms: T/T, Western Union
Supply Ability: 30000 PCS Per month
Price: EXW/FOB/CIF/DDP Raw Material: Cooper
Surface Treatment: Plating Nickel Application: Heat Sink
Processing Service: Cutting, CNC,Anodizing Delivery Time: 20-30days
Keyword: Heat Pipe Radiator
High Light:

Pure Copper Pipe Heatsink


Anti Rust Copper Pipe Heatsink


ISO9001 Laptop Cpu Cooling

Pure Cooper Fin Heat Pipe Radiator For Laptop Cpu Cooler With Rosh


Quick Detail


Raw Material  copper
Custom Service Yes, OEM/ODM Service
Quality System ISO9001:2015
Processing Technology Cutting/Wood machining/CNC/Riveting
Surface treatment plating nickel
Packing Way Blister packaging or special packing you would like
Application Scenario Electronic equipment heat sink
MOQ Request 100/500/1000




    Heat pipe radiator is a new product produced by using heat pipe technology to make major improvements to many old radiators or heat exchange products and systems. There are two types of heat pipe radiators: natural cooling and forced air cooling. The thermal resistance of air-cooled heat pipe radiator can be made smaller, and it is often used in high-power power supplies.




The heat pipe radiator is composed of a sealed tube, a liquid wick and a steam channel. The wick surrounds the tube wall of the sealed tube and is immersed in a saturated liquid that can volatilize. This liquid can be distilled water or ammonia, methanol or acetone. The heat pipe radiator filled with ammonia, methanol, acetone and other liquids still has a good heat dissipation capacity at low temperatures.

The heat pipe radiator is a high-efficiency radiator device with unique heat dissipation characteristics. That is, it has high thermal conductivity, and the temperature distribution along the axial direction between the evaporation section and the cooling section is uniform and substantially equal.
The thermal resistance of the heat sink is determined by the thermal conductivity of the material and the effective area in the volume. When the volume of a solid aluminum or copper radiator reaches 0.006m³, increasing its volume and area will not significantly reduce the thermal resistance. For discrete semiconductor devices that dissipate heat on both sides, the thermal resistance of an air-cooled all-copper or all-aluminum heat sink can only reach 0.04°C/W. The heat pipe radiator can reach 0.01℃/W. Under the condition of natural convection cooling, the performance of the heat pipe radiator can be improved by more than ten times than that of the physical radiator.


The heat pipe radiator has the following advantages:


We can offer the heat pipe radiator service, small qty is acceptable.

High Power Pure Copper Pipe Heatsink 0High Power Pure Copper Pipe Heatsink 1High Power Pure Copper Pipe Heatsink 2High Power Pure Copper Pipe Heatsink 3


Technical Support

We can offer the design and simulation service. For example, our German customer's case.

According to the simulation results,the simulated chip is in compliance with the temperature requirements specficied by customer.

High Power Pure Copper Pipe Heatsink 4
