Rustproof Cooling Liquid Heat Sink High Thermal Dissipation Anti Baking

High Thermal Dissipation Liquid Heat Sink With Technology Support And ISO 9001

Quick Detail

Description

    This heat sink is based aluminum profile 6063-T5 material to processing, first of all, we check the raw material dimension is fine or not, the second is that according to the drawing, cutting right length, the third is that accroding to the drawing, use the wood machine to cut the  outline dimension, the forth is that use the CNC to do exact dimension, the fifth is do anodizing clear, the last step is riveting, and then inspection/packing. First inspection and patrol inspection are done in processing .

Note

Liquid heat sinks are also called water-cooled radiators and liquid-cooled radiators. They are generally made of aluminum and used to dissipate heat. They are mainly used in high-power devices, such as servers, inverters, inverters, APF, SVG, IGBTs, etc., remember to have A company called Fodor Radiator Factory specializes in aluminum radiators, water-cooling plates, etc. This will install the heating element on the water-cooling plate to dissipate heat, and the internal liquid is specially designated.

How is the quality of the water-cooled plate determined?
The quality judgment of water-cooled plate should start from three aspects:
(1) To see the performance, you need to go through the actual test to see the effect. Let the water-cooled board first use the test simulation software to test, get the data, and then put it on the machine for the actual test to see whether the result of the comparison between the two sets of data meets the design requirements. Wenxuan Thermal Energy does just that.
(2) Looking at the process, the water-cooling plate process involves a lot of grooves, pressure pipes, flying surfaces, etc., and the unmature process will cause water leakage and other undesirable phenomena. The surface of the water-cooling plate with mature technology is smooth and the copper tube and the substrate are welded very well. Well, there are no gaps, each interface is stable, and the stability is strong.

Customized Liquid Cooled Heatsinks
With tight collaboration with our customers, we can design and produce almost any kind of copper or aluminium liquid cooled heatsink (other materials on demand). Our designs take in consideration the internal situation of the power chips and an especific water circuit is designed for the optimal refrigeration of the power module. Do not hesitate to ask for your application needs.
Wide Range of Liquid Cooled Heatsinks
Copper and aluminium liquid cooled heatsinks with internal channel for semiconductor cooling through water, glycol and/or oil. Appropriate for high power converters in industrial facilities with cooling circuit systems and heat exchangers. We have a standard range and we can customise any design you require. The new RG82000 series implements new fabrication FSW technology for a very reliable and high performace coldplates. RG78000 series has been specially designed for IHM/IHV y PrimePACK™3 modules. RG77000 as a low cost solution with inserted cooling circuit. RG75000 series for press-pack devices and RG76000 for 62 mm completes the standard product range from our company.

What parameters should be provided in the thermal design of the water-cooled plate?
When designing the heat dissipation of the water-cooling plate, it is necessary to provide the model of the water-cooling plate (that is, the size of the water-cooling plate), the drilling position of the water-cooling plate, the target to be achieved (including temperature difference, water pressure difference, etc.), the parameters of the joint, the power of the heat source, and Calorific value and other data

We can offer the design and simulation service. For example, our German customer's case.

According to the simulation results,the simulated chip is in compliance with the temperature requirements specficied by customer.
